Built in Air Ride System: Instant air ride towing for your pickup & trailer. Absorbs road shock by filtering the bumps, jerks and tugs through the air ride suspension system, which creates a smooth ride & it naturally reduces the tendency of trailer sway. Dual rubber bump cushions also offer additional HD performance.
Smoother Safer Towing:Air ride towing technology with a heavy duty built in air ride system to cushion the ride & absorb the road shock. The air spring sits under receiver tube. Adjust the air pressure for the best ride and load control.
Adjustable Raised Hitch Ball Mount: Adjustable height for raised ball mount (2″ of rise to 2″ of drop). Choose 2″ or 2-5/16″ Chrome Ball.
Safety Red Powder Coat Finish: Impact Resistant Textured Premium Powder-Coat Finish on Hitch & Matte Black on Raised Mount.
14,000 GTW Capacity: 14,000 lbs towing capacity & 1,400 lbs tongue weight. Great for boats, campers, enclosed trailers and more.
2 Hole Receiver Shank: Available for 2″ & 2 1/2″ receiver hitch tubes with Two hitch pin holes for length adjustability.
Saves Fuel: By reducing the jerks, tugs and sways, customers report getting 1 or more miles per gallon improvement.
Adds Life To Your Vehicle: By reducing wear and tear on driveline and frame! Treat yourself, your equipment, and your passengers to a much smoother ride. You’ll never go back to the ‘old days’ of continual bumps, jerks, and vibrations.
Great for Pickups: Fits Pickup Trucks, Vans. Also fits Select SUVs with receiver hitch below bumper. Popular installs include GMC Sierra, Chevy Silverado, Chevy Colorado, GMC Canyon, Dodge Ram, Ford Ranger, Maverick F150, F250, F350, F450, F550 Superduty, Toyota Tundra, Tacoma, Nissan Titan, Frontier, Honda Ridgeline & Hyundai Santa Cruz.
Air Hitch Kit includes complete Shocker air receiver hitch with built in air ride system & dual bump cushions, adjustable raised ball mount with 2″ or 2-5/16″ chrome trailer hitch ball and 3 d-handle ball mount hitch pins.
Improves Safety: By giving you improved control of your tow vehicle and trailer. The air ride receiver hitch system allows for better control of your pickup and the trailer it is towing.
Simple Pivot Design: uses a rocker arm pivot design which produces a down and back motion, much different than other air hitches on the market. Our design eliminates the need for slides, parallel linkages, rollers, shock absorbers, or multiple air ride systems common to other air hitches.
Saves Money: By reducing trailer breakage on both the trailer and the trailer contents! The Shocker hitch absorbs the damaging forces experienced with a typical hard connection. This greatly reduces the chances of breaking welds and doing other long term damage to your equipment as well as the valuable cargo you have inside the truck and trailer.
20+ Ball Mount Options: Huge selection of ball mount attachments available from combo ball, drop, raised, drawbar, clevis pin, clevis, sway bar tab options, pintle hook, pintle & ball attachments and more. Combo adjustable multi-ball mount has 2″ & 2 5/16″ hitch ball.
Safety Notice: Towing capacity is limited by lowest rated component. Manufactured by Shocker Hitch® USA in Jamestown, ND. 2″ Ball is 10,000 lbs GTW & 1,000 lbs TW / 2-5/16″ Ball is 20,000 lbs GTW & 2,000 lbs TW.
The Shocker Air Ride Receiver Hitch with a raised ball mount comes with a 2″ or 2-5/16″ chrome hitch ball with 2″ of rise to 2″ drop, 14,000 lbs tow rating capacity and 1,400 lbs tongue weight. Shocker air provides the ultimate smooth ride, and the raised ball mount is often used with camper towing when your camper trailer has a higher tongue. Works great for pulling a camper, ice houses, equipment & cargo trailers, and more. The Shocker Air is a miniature air suspension unit mounted between your pickup truck and trailer. This shock-absorbing trailer hitch mounts by sliding into a standard receiver tube. The pivoting design filters the bumps and bangs through the built in air ride system, creating a way smoother and safer trailer towing experience. Plus, it saves you money by reducing trailer breakage on both the trailer and the trailer contents! The Shocker hitch absorbs the damaging forces experienced with a typical hard connection. This greatly reduces the chances of breaking welds and doing other long term damage to your equipment as well as the valuable cargo you have inside the truck and trailer. The Shocker air with standard ball mount is great for pickup trucks, vans and select SUVs where the receiver tube is under the bumper. This shock absorbing hitch is a must have for smoother trailer towing. The built in air spring bag lasts for years and does a wonderful job of smoothing out your towing experience by cushioning both your tow vehicle and the trailer. The air ride system sits under the receiver tube, allowing a short distance of 10-inches between the mounting pin and ball center. The advantage of the Air Shocker is your ability to adjust air pressure for the best ride and load control. Plus, the drop range is great for stock pickup trucks. Shocker air bumper hitch offers a shock dampening action & effectively absorbs the jerking, tugging and damaging forces experienced with a typical hard connection when towing trailers. There is no reason to beat yourself or your equipment up with a hard connection between your trailer and your receiver hitch.
The raised ball mount is matte black impact resistant textured powder-coated with a bolted on chrome hitch ball for maximum strength and the hitch is powered coated safety red. Have a CUV? Check out our Cushioned Ball Mounts. Manufactured by Shocker Hitch® USA in Jamestown, ND
Air Bumper Hitch Mount Drop & Rise + Tow Rating Guide
– Combo Ball: 0″ Rise to 4.5″ Drop | 2-5/16″ ball rated at 20,000 lbs & 2″ ball rated at 10,000 lbs.
– Drop Ball: 4.5″ to 8.5″ Drop | 2-5/16″ ball rated at 20,000 lbs & 2″ ball rated at 10,000 lbs.
– Raised Ball: 2″ Rise to 2″ Drop | 2-5/16″ ball rated at 20,000 lbs & 2″ ball rated at 10,000 lbs.
– Pintle Hook: 2.5″ Rise to 6.5″ Drop | 10-Ton 20,000 lbs.
– Pintle & Ball: 2.5″ Rise to 6.5″ Drop | 8-Ton 16,000 lbs. (2″ Ball is 10,000 lbs).
– Drawbar: 0″ Rise to 4.5″ Drop | 20,000 lbs.
– Clevis Mount: 3.5″ Drop to 7.5″ Drop | 20,000 lbs.
– Sway Bar Mounts: Same Rating as Like Type Mount Listing Above.
Safety Notice: Towing capacity is limited by lowest rated component.
Select your hitch to jump to its installation instructions.
Set up your air receiver hitch
Follow the installation steps for your model, then adjust air pressure with your trailer loaded for travel. Use these shortcuts for setup help and maintenance.
Set air pressure for your loaded trailer
100 PSI MAXIMUM — not the target setting. Use the truck-side bump cushion to judge the correct adjustment for your load. Never exceed 100 PSI.
Load and connect your trailer. Follow your model’s installation steps and set up the trailer as you normally would for travel.
Add air at your model’s valve. The photos below show where the air compressor connects.
Watch the truck-side bump cushion. Stop adding air once the main frame lightly compresses the cushion closest to the truck (tailgate side). Follow the detailed instructions for your model below.
Standard / HD air receivers Add air at the valve shown where the compressor connects. Air-pressure stepsSport™ air receiver Locate the valve shown in this close-up. Air-pressure stepsTrail Force® air receiver The air valve is below the air spring. Air-pressure steps
Truck-side bump cushion at the correct light compression.
Watch this cushion—not a preset PSI number
Observe the cushion closest to the truck. With the trailer loaded, add air until the main frame lightly compresses that cushion. The pressure needed depends on the load.
Recheck the adjustment when your trailer load changes. The 100 PSI limit is a ceiling, not an instruction to inflate to 100 PSI.
Select any photo to open the full-size labeled guide in a new tab.
Air valve — add air at the valve shown. Enlarge photoPaddle — the flat steel plate above the air spring. This example also shows an installed spacer block. Enlarge photo
Shocker Air Receiver Hitch Install Video
Note: Always use a good hitch ball rated for the recommended tow weight.
Safety Notice: Towing capacity is limited by the lowest rated component.
Shocker Air Receiver Hitch Installation Instructions
1. Compressing Air Spring (BEFORE INSTALLATION)
• Release Pressure: Use the provided cotter pin clip to push in on the valve core to release air pressure from the back.
• Compress: While releasing pressure, simultaneously push down on the air spring paddle or squeeze the plates together to exhaust the remaining air.
2. Installing the Shocker Hitch into the Receiver
• Mounting: Slide the hitch shank fully into the receiver tube of your tow vehicle.
• Align and Secure: Align the pin holes and insert the 5/8” hitch pin. Lock it in place with the cotter pin clip.
• Attachment: Install your chosen mount into the Shocker Hitch Frame.
• Secure: Use the hitch pins and cotter pin clips provided to lock the ball mount into place.
4. Setting Air Pressure
• Load the Trailer: Hook up your trailer and load it as you normally would for travel.
• To Set Air: Hook up trailer using a properly selected ball adaptor and height adjustment to level trailer when loaded. Next, inflate the air spring. As air pressure increases, the unit will rotate, lifting the hitch point. Install enough air until the top of the hitch frame touches the top (tailgate side) bump cushion, or for heavy loads, until it compresses the tailgate side bump cushion by approximately 1/8″.
The “Sweet Spot”
Stop adding air once the main frame lightly compresses the truck side bump cushion.
Proper Air Pressure Guide
Truck-side bump cushion touching the frame — stop adding airTruck side bump cushion-green-not touching frame (Add Air)
Spacer-block decision guide
Check alignment with your trailer connected, loaded for travel and the air pressure correctly set. The paddle above the air spring should be approximately parallel with the receiver tube.
When is a spacer block needed?
1. Correct alignment Paddle approximately parallel with the receiver tube. A spacer is not needed to correct the angle shown.2. Excessive angle If the paddle angle is more than 10 degrees with pressure correctly set, follow the spacer-block guidance for your model.3. Corrected alignment The spacer sits on top of the paddle against the underside of the receiver tube, correcting the excessive angle.
Model notes: 20K HD hitches with a 2-inch receiver come with the spacer installed. Some HD models with a 2-1/2-inch receiver include it in the box. A spacer is generally not needed on 14K air receiver hitches because their air spring is 1 inch taller than the HD air spring.
Maximum air pressure: 100 PSI. Do not use extra air pressure to exceed this limit while checking alignment. Read the full spacer-block guide.
Watch: when do you need a spacer block?
Use this short video alongside the alignment photos above to understand the spacer-block setup.
• Attachment: Install your chosen mount into the Shocker Sport Hitch Frame.
• Secure: Use the hitch pins and cotter pin clips provided to lock the ball mount into place.
4. Setting Air Pressure
• Load the Trailer: Hook up your trailer and load it as you normally would for travel.
• To Set Air: Hook up trailer using a properly selected ball adaptor and height adjustment to level trailer when loaded. Next, inflate the air spring. As air pressure increases, the unit will rotate, lifting the hitch point. Install enough air until the top of the hitch frame touches the top (tailgate side) bump cushion, or for heavy loads, until it compresses the tailgate side bump cushion by approximately 1/8″.
The “Sweet Spot”
Stop adding air once the main frame lightly compresses the truck side bump cushion.
Trail Force Receiver Hitch Installation Instructions
1.Installing the Trail Force Air Hitch into the Receiver
• Mounting: Slide the hitch shank fully into the receiver tube of your tow vehicle.
• Align and Secure: Align the pin holes and insert the 5/8” hitch pin. Lock it in place with the cotter pin clip.
• Attachment: Install your chosen mount into the Trail Force Hitch Frame.
• Secure: Use the hitch pins and cotter pin clips provided to lock the ball mount into place.
3. Setting Air Pressure
• Load the Trailer: Hook up your trailer and load it as you normally would for travel.
• To Set Air: Hook up trailer using a properly selected ball adaptor and height adjustment to level trailer when loaded. Next, inflate the air spring. As air pressure increases, the unit will rotate, lifting the hitch point. Install enough air until the top of the hitch frame touches the top (tailgate side) bump cushion, or for heavy loads, until it compresses the tailgate side bump cushion by approximately 1/8″.
The “Sweet Spot”
Stop adding air once the main frame lightly compresses the truck side bump cushion.
Download Shocker Air Receiver Hitch Install Instructions
Shocker Air Receiver Hitch Air Pressure PSI Tuning Video
Air receiver hitch troubleshooting
Start with your trailer connected and loaded for travel. Follow the instructions for your model above; do not use extra air pressure or bolt adjustments to compensate for an incorrect setup.
The ride feels stiff
Recheck the air setting against the truck-side bump cushion rather than aiming for a preset PSI. The main frame should lightly compress that cushion. Check routine lubrication, too.
Do not tighten the top jamnut bolt (limiter bolt). If it has already been adjusted, contact our team before making further adjustments.
A changed trailer load, temperature change or a new air spring settling can affect pressure. Recheck the loaded setup. Persistent or substantial pressure loss needs a leak check; use the air receiver section of our detailed guide.
Never inflate an air spring outside its hitch frame. If the spring will not hold air or appears damaged, contact our team before towing.
With air pressure correctly set, compare your setup with the three alignment examples. The paddle above the air spring should be approximately parallel with the receiver tube. Spacer requirements depend on the model and receiver size.
Routine Lubrication • Pivot Bolt: Regularly grease the Shocker Hitch unit using the built-in grease zerk located on the main pivot bolt. • Over-Greasing: You cannot over-grease the unit; frequent lubrication ensures the air-ride pivot remains fluid and responsive. • Hitch Ball: It is highly recommended to grease the trailer coupler ball to reduce friction and prevent premature wear.
Critical Adjustments • Top Jamnut Bolt: DO NOT tighten the top jamnut bolt. • Factory Specs: This bolt is set to factory specifications out of the box; overtightening will cause a stiff towing experience and limit the airbag’s effectiveness. • Attachment Swapping: When changing between different ball mounts (Combo, Pintle, Clevis, etc.), ensure the pins and cotter pin clips are fully seated and locked.
Air System Integrity • Max Pressure: Never Exceed 100PSI in the air spring. • Component Protection: Excessive pressure can lead to permanent damage to the air spring or the internal bump cushions. • Pre-Tow Inspection: Always check your air pressure after loading the trailer to ensure the frame is lightly compressing the bump cushion.
Quick answers for standard and HD air receivers, Sport™ and Trail Force® models.
How much air pressure should I use?
There is no single PSI setting for every trailer. With the trailer connected and loaded, add air until the main frame lightly compresses the truck-side bump cushion, following your model’s steps. Recheck after changing the load. 100 PSI is the maximum, not the target.
Use the air valve shown for your model. Watch the cushion nearest the truck, also called the tailgate-side cushion. The paddle is the flat steel plate above the air spring; the limiter bolt is not an air-pressure adjustment.
Check the paddle angle with the trailer loaded and air pressure set. An angle greater than 10 degrees calls for reviewing the spacer guidance for your model. The 20K HD with a 2-inch receiver comes with the spacer installed; some HD 2-1/2-inch models include it in the box. A spacer is generally not needed on 14K air receivers.
How do I choose the receiver size and ball-mount height?
Measure the inside opening of your vehicle’s receiver and match the hitch shank to it. Select a ball mount with enough drop or rise to keep the loaded trailer level, then check ground clearance.
Can I use a weight-distribution hitch or friction sway control?
The air receiver hitches covered here are not for use with a weight-distribution system. See the Shocker Air Equalizer for that application and confirm compatibility with your setup. Friction sway control requires the appropriate sway-bar-tab ball mount and compatible sway-control components; it is a different setup from weight distribution.
No. Stay within the vehicle, receiver, hitch, ball mount, ball, coupler and trailer ratings. The lowest-rated component limits the setup, including its applicable tongue-weight limit.
Check that the receiver pin, attachment pins and their retaining clips are fully secured; the coupler is locked on the correct ball; and the safety chains and electrical connection are in place. Confirm loaded trailer height, ground clearance and air adjustment, then complete the full pre-tow checks.
How do I choose a replacement air spring or cushion?
Match the part to your exact hitch model and air-valve or air-line configuration. Do not select by appearance alone. Use the replacement-part links on this page, or send our team your model number and a photo before ordering.
What is the distance between the centre of the hole in the shank to the centre of the tow ball, I need at least 12"
0 votes
QWhat is the distance between the centre of the hole in the shank to the centre of the tow ball, I......
Read more
A
From the center of the shank to the top of the ball is roughly 6"
I have purchased a HD shocker hitch. It is about 3” too low when set at it highest setting on my tow bar. Is there a system which allows higher mounting available?
0 votes
QI have purchased a HD shocker hitch. It is about 3” too low when set at it highest setting on my ......
Read more
A
Unfortunately we do not have one with a taller rise. The only option we have with a 5" rise is the Shocker Impact hitch that does not have the air bag system.
I have purchased a HD shocker hitch. It is about 3” too low when set at it highest setting on my tow bar. Is there a system which allows higher mounting available?
0 votes
QI have purchased a HD shocker hitch. It is about 3” too low when set at it highest setting on my ......
Read more
AAt this time no, this is the largest rise we offer for the HD air hitch.
