Vertical Channel Weld On Tongue Adapter for Trailer A-Frames

Select Option:

Clear

Product Information:

List Price: $124.99$159.99Sale Price: $99.74$128.24Free Ground Shipping*

Money IconExtra 5% OFF, hurry limited time offer.
Reviews
Rated 5.00 out of 5 based on 9 customer ratings
SKU: SH-410-X

-

Product Description

  • Trailer Tongue Vertical Channel Style Weld On Adapter for Trailer A-Frame
  • Convert your trailer a-frame to one that accepts Vertical Channel couplers
  • Equipped with 6 Adjustment Holes – Actual vertical channel is 3-1/2″ x 11-3/4″ w/ 2″ on center bolt pattern
  • Converts a Typical 50-degree Trailer Tongue Into a Vertical Channel
  • The outer front is 4″ wide, the outer rear is 11″ wide. From front to back it measures 7-1/2″.
  • Welding required for installation
  • Weight Rating: If you are using 2 bolts to attach coupler then its 14,000 lbs if using 4 bolts then 20,000 lbs that also assumes this kit is properly weld onto the trailer and the coupler you are using can handle those respective capacities.

Works with Shocker Trailer Tongue Mounts with Vertical Channels:  Shocker Coupler Trailer Tongue Mount  & Shocker Pintle Ring Trailer Tongue Mount

The Trailer Tongue Vertical Channel mount adapter for your trailer a-frame is a weld on adapter that converts your typical horizontal trailer tongue to accept a vertical channel type coupler. This weld on vertical channel mount has 6 adjustment holes.  The six bolt hole pattern works great with typical vertical channel trailer couplers. Available completely welded, spot welded or just the components. Perfect for modifying a trailer or when building a custom trailer.  The outer front is 4″ wide, the outer rear is 11″ wide. From front to back it measures 7-1/2″.

Weight Rating: If you are using 2 bolts to attach trailer coupler then its 14,000 lbs if using 4 bolts then 20,000 lbs that also assumes this kit is properly weld onto the trailer and the coupler you are using can handle those respective capacities.

California Resident: Prop 65 Warning

Warranty

This product is back the Shocker Hitch Manufacturer Warranty and the Shocker Hitch Guarantee.

Shocker Hitch Guarantee

Questions and answers of the customers

    Do you offer install service at your location?
  1. 0 votes
    Q Do you offer install service at your location?
    A

    Unfortunately, we do not offer install services at our shop at this time. However, if you check with one of your local trailer dealers they may be able to help you get that installed. Here is a link to our Dealer locator https://shockerhitch.com/dealers/

  2. Does the completely welded version only mount one way or can it be installed either way?
  3. 0 votes
    Q Does the completely welded version only mount one way or can it be installed either way?
    A

    The vertical mount channel can be mounted upside down in some applications. We also have a tack welded version that can be used to help fit it to your trailer and then be welded.

  4. Hi, Can this be ordered without the holes for the jack, just a solid top plate? Thanks!
  5. 0 votes
    Q Hi, Can this be ordered without the holes for the jack, just a solid top plate? Thanks!
    A

    Hello Chris, unfortunately the adapter is precut with the holes for a jack already  in it.

  6. What is the diameter of the hole for the Jack ?
  7. 0 votes
    Q What is the diameter of the hole for the Jack ?
    A The weld on vertical channel adaptor has the hole and three bolt pattern that is standard issue for most any camper tongue center mount jack. The hole diameter is 2 3/8" diameter.
  8. What is the max tongue weight using this with the 2 5/16 ball air ride
  9. 0 votes
    Q What is the max tongue weight using this with the 2 5/16 ball air ride
    A When using the Shockerhitch tongue mount hitch, this should be good for atleast 2000 lbs as the tongue mount shockerhitch is rated.
  10. What is the max tongue weight using this with the 2 5/16 ball air ride
  11. 0 votes
    Q What is the max tongue weight using this with the 2 5/16 ball air ride
    A

    When using the Shockerhitch tongue mount hitch, if using two bolts two mount the GTW is 1,400 lbs when using 4 bolts to mount the GTW is 2,000 lbs.

  12. Weight limit or max limits on this item??
  13. 0 votes
    Q Weight limit or max limits on this item??
    A If you are using 2 bolts then 14,000 lbs if using 4 bolts then 20,000 lbs that also assumes this kit is properly weld onto the trailer. You will also want to use a coupler that is rated at that capacity as well.
  14. What is the recommendations for max load capability for this item? I’m ordering the item pre-welded and requires spot welding for connections to trailer frame. Thanks
  15. 0 votes
    Q What is the recommendations for max load capability for this item? I’m ordering the item pre-weld...... Read more
    A If you are using 2 bolts then 14,000 lbs if using 4 bolts then 20,000 lbs that also assumes this kit is properly weld onto the trailer.

Send me a notification for each new answer.

9 reviews for Vertical Channel Weld On Tongue Adapter for Trailer A-Frames

Add a review

Your email address will not be published. Required fields are marked *

Customer Reviews

  1. The tongue was a perfect upgrade to my car trailer that had a bent coupler. My welder/fab guy said that it was great quality steel that was good to work with. Shocker hitch was great to work with very well priced and got my parts quick

    – Tyler
  2. Any know if I can get this a-frame coupler in Ontario Canada ?(toronto )

    – Steven Horvat
  3. Fantastic product! Exactly what I was looking for. Versatile for most any applications and great quality.

    – Brennen Gilson
  4. Excellent product! I will use these systems from this point forward. Very Quality!
    M. Jay Hurles

    – M. Jay Hurles
  5. Absolutely the way to go if you intend to enjoy the luxury of installing and towing with the Shocker Air Trailer Tongue Coupler. I’m glad the team at Shocker recommended this component that they have perfected. I installed the unit myself, and while I’m a pretty good welder this made the job picture perfect!

    – Marlin J Hurles
  6. Great design. Great customer service. Great product. Very easy to install (weld) on to my trailer. I’ll upload some pics when I’m complete.

    – Duane
  7. Great customer service and I’m sure the product quality will be great. Answered all of my questions quickly & gave professional advice on installation techniques. Went out of the way to get my parts to the shipping company so I didn’t have to wait till Monday the next week.
    Will definitely get something else here.. Thanks!

    – Larry Brand
  8. Came as described, was easy to assemble and weld on. Only thing I will reccomend is if your not a confident welder pay one to do it or have them pre weld it. I’ve seen some pretty sketchy things in my line of work in 34 years and other people’s lives could be at risk including yourself. All in all a super quick install with accurate and clean cut pieces ready to assemble.

    – Dennis Dixon
  9. Perfect, cut the old ball hitch off, weld the new one on.

    – don p.

Weight / Dimensions

Weight 30 lbs
Dimensions 12 × 10 × 9 in
Select Tongue Style

Completely Welded, Components Only – 2 sides, base & vertical channel, Spot Welded
